Product Details:
|
| Plastic Processed: | PP, PC, ABS, PVC, PE, PE/PP | Condition: | New |
|---|---|---|---|
| Style: | VERTICAL | Plasticizing Capacity(g/s): | 41/57 |
| Mold Height(mm): | 60 - 160 Mm | Ejector Stroke(mm): | 125 Mm |
| Ejector Force(kN): | 20 KN | Theoretical Shot Volume(cm³): | 100 Cm³ |
| Injection Rate (g/s): | 70 G/s | Machine Type: | Hydraulic |
| Injection Weight (g): | 100 G | Screw Speed (rpm): | 1 - 260 Rpm |
| Screw Diameter (mm): | 26 Mm | Weight (KG): | 1500 Kg |
| Open Stroke(mm): | 200 Mm | Power (kW): | 8.7 KW |
| Warranty: | 2 Years | Key Selling Points: | High-accuracy |
| Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Home Use, Retail, Energy & Mining | Showroom Location: | None |
| Machinery Test Report: | Not Available | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | Core Components: | Motor, PLC |
| Marketing Type: | Ordinary Product | Port: | Shenzhen |
| Note 1: | We can open molds according to customers' products and customize injection molds. |
| Note 2: | We can also increase the configuration of the machine according to the needs of customers, we support one customization, one purchase |
