External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type

Certification
China Yihan (shenzhen) Automation Equipment Co., Ltd. certification
China Yihan (shenzhen) Automation Equipment Co., Ltd. certification
I'm Online Chat Now

External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type

External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type
External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type

Large Image :  External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type

Product Details:
Place of Origin: Guangdong, China
Brand Name: Yihan
Model Number: YH-H806
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $800.00/sets 1-2 sets
Packaging Details: Wooden package

External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type

Description
Usage: Cutting/peeling, Stripping And Cutting Name: Wire Stripping Machine
Model: YH-H806 Size: 450x430x320mm
Weight: 29KG Stripping Length: Head 0 - 100mm Tail0-60
Cutting Length: 0.1-9999mm Display Method: Chinese Or English
Stripping Range: External Diameter 1-6mm Power Supply: 220V /110V 60Hz/50Hz

External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 0External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 1External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 2

Automatic sheath type computer cutting and stripping machine

Features:

The machine uses the latest 32 intelligent control system, Chinese and English switching liquid crystal display, button operation, can store hundreds of pieces of information, called at any time, fast efficient,Compatible with the general features of 220 # wire cutting machine.Double linear,two wires can be processed simultaneously,not only saves labor and time,but also improve productivity.Mainly used for electronic wire, silicone wire,Teflon wire, glass fiber of cotton,isolated lines,coaxial,trunking.Automatic cutting, stripping, semi-stripping,multi-segment stripping , twisting function once completed, can instantly transform wire specifications and dimensions,it’s very economic. The machine is mainly used in electronics, electrical appliances, toys, auto parts and other industries.

External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 3

Product Description
Type YH-H806
Size 470mm×450×340
Weight 45kg
Display method Chinese or English interface display
Power supply AC220/50Hz
Capacity  420W
Cutting length 1mm---99999mm
Cutting Tolerance Modifiable
Peeling length 1.0mm-100mm(According to the wire)
Applicable wire core area The outer diameter of 1.5mm to 6mm
Productivity 3500-5000pcs/h(according to the cutting length)
Tool Material Tungsten steel / white steel
Warranty Motherboard and screen are guaranteed for 3 years
Cable outer diameter Adjustable
Stripping quality Excellent
Decimal precision Yes
Drive mode Four simultaneously drive
Stripping pressure adjustment: Adjustable
Speed adjustment 0-9
Stripping Mode long wire/ short wire /Multi-stripping / multi stripping

External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 4External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 5External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 6External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 7External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 8External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 9

Product Show

External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 10

Company profile

External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 11External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 12External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 13External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 14External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 15External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 16External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 17External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 18

Advantages

External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 19

Certification

External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 20

Packaging delivery

External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 21

Problem solving

External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 22

Contact us

External Diameter 1-6mm Wire Cutting and Stripping Equipment Automatic Sheath Type 23
