Product Details:
|
| Usage: | Stripping And Cutting | Power: | 220V/110V 50-60HZ |
|---|---|---|---|
| Available Wire Size: | OD 1-9MM | Stripping Length: | Head 0-100mm,Tail 0-100mm |
| Cutting Length: | 1-99999.99mm | Cutting Tolerance: | ±(0.002*L)(L=Cutting Length) |
| Speed: | 1000-4000pcs/h | After-sales Service: | On-line Support |
| Warranty: | 1 Year | Weight: | 33kg |
| Size: | 450*550*400 Mm |
| Model | YH-DL806 | YH-DL810 | YH-DL816 | YH-DH-809 |
| Wire Size | AWG10-AWG32 | AWG8-AWG32 | AWG6-AWG32 | AWG6-AWG32 |
| Conductor Cross-Section | 0.5-6MM2 | 0.5-10MM2 | 1-16MM2 | OD 1-9MM |
| Cutting Length | 1-99999.99MM | |||
| Cutting Tolerance | ±(0.002*L)(L=Cutting Length) | |||
| Stripping Length | Head:0-25MM Tail:0-25MM | Head:0-25MM Tail:0-60MM | Head:0-25MM Tail:0-60MM | Head:0-100MM Tail:0-100MM |
| Conduit Diameter | ø6mm | ø8mm | ø9mm | ø10mm |
| Production Rate | 4000-6000 PCS/H (Depend on wire) | 2000-3000PCS/H (Depend on wire) | ||
| Power Supply | 220V/110V 50-60HZ | |||
| Power | 400W | 450W | 500W | 500W |
| Weight | 28kg | 30kg | 33kg | 35kg |
| Size | 400*450*380MM | 400*450*380MM | 430*480*400MM | 450*500*450MM |
| Note: Mark parameters custom available,if you are in doubt,we are happy to process your sample | ||||
