Product Details:
|
| Usage: | Tying | Length Of Tie: | 200-300mm |
|---|---|---|---|
| Strapping Range: | 40-80mm | Wire Binding Speed: | 1 S/pcs |
| Wire Range: | 1-8mm | Size: | 550*550*500MM |
| Weight: | 35KG | Power Supply: | <200W |
| Power: | AC220V/110V 50-60HZ | Warranty: | 12months |
| After-sales Service: | On-line Support |
1: The operation is simple, just place the product in the binding position and push gently to complete the binding
2: The machine automatically sends cable ties, automatically cuts cable ties, and automatically twists cable ties
3:This machine has a wide range of applications, and can use iron core ties and gold wire ties
Applicable to: cable ties in various industries such as wire, hangers, candy, bread bags, bouquets, gifts, sanitary hoses, etc.
| Tying Wire Length | 200-300MM |
| Cable Tie | Rubber Wrapped Iron Wire/gold wire tie |
| Suitable Coil Diameter for Tying | φ40-80MM(Customized Other Size) |
| Efficiency | 1 s/pcs |
| Voltage | 220V 50/60HZ |
| Rated Power | <200W |
| Size | L500*W450*H300MM |
| Weight | 35KG |
| Model | YH-5-30Z | YH-5-50Z | YH-8-30Z | YH-18-45Z |
| Photo | | | | |
| Cable Tie Length | 75-140MM | 75-220MM | 80-140MM | 120-200MM |
| Strapping diameter | Φ5-30MM | Φ5-50MM | Φ8-30MM | Φ18-45MM |
| Power Supply | 220V 50-60HZ | 220V 50-60HZ | 220V 50-60HZ | 220V 50-60HZ |
| Size | 350*300*300MM | 350-300-300MM | 500*520*500MM | 600*700*650MM |
| Weight | 25KG | 30KG | 40KG | 42KG |
| Model | YH-5-30-ZT | YH-5-50-ZT | YH-8-30-ZT | YH-18-45-ZT |
| Photo | | | | |
| Cable Tie Length | 75-140MM | 75-220MM | 80-140MM | 120-200MM |
| Strapping diameter | Φ5-30MM | Φ5-50MM | Φ8-30MM | Φ18-45MM |
| Power Supply | 220V 50-60HZ | 220V 50-60HZ | 220V 50-60HZ | 220V 50-60HZ |
| Size | 350*300*300MM | 350-300-300MM | 500*520*500MM | 500*520*500MM |
| Weight | 25KG | 38KG | 40KG | 42KG |
| Model | YH-40-80-ZT |
| Photo | |
| Cable Tie Length | 220-300MM |
| Strapping diameter | Φ40-80MM |
| Power Supply | 220V 50-60HZ |
| Size | 600*700*600MM |
| Weight | 60KG |
